AOC 24.1′ Fast TN panel,1920 × 1080 , 610Hz, 0.5ms, HDR400, Removable Ergonomic stand , G-sync Compatible Gaming Monitor ( LS)

Description

AOC 24.1′ Fast TN panel,1920 × 1080 , 610Hz, 0.5ms, HDR400, Removable Ergonomic stand , G-sync Compatible Gaming Monitor

Get ready to break boundaries with the CS24A/P – a revolutionary collaboration built exclusively for Counter-Strike 2. Featuring an astonishing 610Hz refresh rate on a lightning-fast 24′ TN eSports panel, this monitor delivers visuals so fluid, it feels like the game moves with you. With G-Sync, ultra-low input lag, and a game-changing CS Mode, you’ll experience every clutch moment with pinpoint precision. Designed for the pros, the CS24A packs HDR400, HDMI 2.1, bold RGB Light FX, and an ergonomic stand for full-battle comfort. Topped off with G-Menu control and a high_x0002_octane design, the CS24A isn’t just a monitor—it’s your ticket to domination. This is next-level eSports performance, redefined.

Specifications

Picture / Display

‘

‘

Response Time (typical)

Connectivity

DisplayPort 1.4 × 1 (HDR)

mini USB (for key pad) × 1

Convenience

Game Mode / Left

Menu / Enter / Power

Increase / Right

Français

Español

Português

Deutsch

Italiano

Nederlands

Svenska

Suomi

Türkçe

Polski

Čeština

Русский

한국어

繁體中文

简体中文

日本語’

Stand

Power

Dimensions

Weight

Operating Conditions

Storage Conditions

Sustainability

Recyclable Packaging Material Yes

Compliance and Standards

FCC

Color

Specifications

Model name	CS24A/P
EAN code	6973985233111
LCD Panel Type	Fast TN LCD –> E-SPORT TN
Backlight Type	W-LED system
Panel Size	24.1′
Effective Viewing Area (mm)	535.68(H) × 298.08 (V)
Aspect Ratio	16 : 9
Optimum Resolution	1920 × 1080 @ 610Hz – DisplayPort1.4+DSC,HDMI2.1
Scan Frequency	30K~510KHz (H) / 60~610Hz (V)
Smart Response Time (typical)	0.5ms (GtG) / 0.3ms (MPRT)
Brightness (Peak for HDR)	500 cd/m²
Brightness (typical)	350 cd/m²
Smart Contrast	80 Million : 1/MEGA DCR
Contrast Ratio (typical)	1000 : 1
Pixel Pitch (mm)	0.279 (H) × 0.276 (V)
Viewing Angle	176° (H) / 170° (V) (CR > 5)
Display Colors	16.7 Million
Color Gamut	sRGB 99% (CIE1931) / DCI-P3 90% (CIE1976)
Color Accuracy	Delta E < 2
Low Input Lag	Yes
PxP (PIP, PBP)	PBP / PIP
HDR	HDR400
Gaming Motion Technology	AdaptiveSync (G-sync in processing)
Signal Input	HDMI 2.1 × 2 (HDR)
HDCP Version	HDMI: 2.3 / DisplayPort: 2.3
MHL	no
USB Connector	USB 3.2 Gen1 × 4
Line In/Earphone	Earphone × 1
Others	CS Light, Boot up logo, CS mode
Built-in Speakers	no
User Controls	Source / Up
OSD Languages	English
Plug & Play Compatibility	VESA DDC2B/CI
Software Certification	Windows 11 / Windows 10
Height Adjustment	130 mm
Pivot	90°–>-90°~90°
Swivel	—30° ~30°
Tilt	—5° ~ 23°
Smart Power Mode: Maximum	107W
Smart Power Mode: Typical	30W
Standby Mode	0.5W
Off Mode	0.3W
Power LED Indicator	Operating: Red
Power Supply	Internal 100 – 240V～1.5A, 50 / 60Hz
Product without Stand (mm)	331.4 (H) × 557.0 (W) × 73 (D)
Product with Stand (mm)	380.8~489.8 (H) × 557.0 (W) × 240 (D)
Packaging (mm)	420 (H) × 650 (W) × 188 (D)
Wall Mount	100mm × 100mm
Product without Stand	3.75 kg
Product with Stand	5.03 kg
Product with Packaging	8.45 kg
Temperature Range (Operating)	0° ~ 40°
Relative Humidity (Operating)	10% ~ 85%
Altitude (Operating)	0 ~ 5000m (0 ~ 16404 ft)
MTBF	50000hours
Temperature Range (Storage)	—20° ~ 55°
Relative Humidity (Storage)	5% ~ 93%
Altitude (Storage)	0 ~ 12192m (0 ~ 40000 ft)
Environmental and Energy	RoHS
Regulatory Approvals	CE
Cabinet	Black & Gold

Product Details

• Brand: AOC
• Manufacturer Part No: CS24A/P
• Our Part No: MNAO-CS24AP
• Warranty: 36 Months (3 Years)
• Shipping Weight: 9.40 kg
