Description
SPECIFICATION
Model Name
SPATIUM M480 PCIe 4.0 NVMe M.2
Capacity
1TB
Controller
PHISON E18
Flash Memory
3D NAND
Dram Cache
1GB DDR4
Form FActor
M.2 2280
Interface
PCIe Gen4x4, NVMe 1.4
Compatibility
PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions
80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s)
7400
Sequential Write up to (MB/s)
6000
Random Read 4KB up to (IOPS)
750,000
Random Write 4KB up to (IOPS)
1,000,000
Maximum Operating Power (W)
9.5
Idle Power PS3 (mW)
40
Low Power L1.2 (mW)
3
Operating Temperatures
0°C – 70°C
Storage Temperatures
-40°C – 85°C
Terabytes Written (TBW)
700
Mean Time Between Failure (MTBF)
Up to 1,600,000 Hours
Limited Warranty
5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
Advanced Features
TRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/Pyrite (Encryption, Data Security)
Product Details
- Brand: MSI
- Manufacturer Part No: SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB
- Our Part No: HBM-SPATIUMM480PRO-1TB
- Warranty: 60 Months (5 Years)
- Shipping Weight: 0.04 kg
Buying From BITS Perth
Supplied by BITS Perth, a Western Australian IT provider based in Clarkson. Prices are in AUD and include GST. Flat-rate shipping is $15 Australia-wide and free on orders over $1,000. Orders ship in 2–3 business days with full manufacturer warranty.
Need advice or a bulk quote? Call 0477 032 032 or email admin@bitsperth.com.au.
